Automatic Smoothness Tester

Automatic Smoothness Tester Introduction

Automatic smoothness tester is an intelligent paper and cardboard smoothness performance testing instrument newly designed and developed according to the principle of the internationally accepted Buick Bekk smoothness meter. The mechanical design of the instrument cancels the traditional lever-weighted hammer structure for manually applying pressure, innovatively uses a cam plus a spring, and uses a synchronous motor to automatically rotate and load the standard pressure. Greatly reduce the size and weight of the instrument. It is used to measure the surface smoothness of paper and cardboard, and it is a satisfactory testing equipment for paper making, packaging, printing, commodity inspection, scientific research and other departments.

Automatic Smoothness Tester Application

Paper, cardboard (not suitable for paper and cardboard with a thickness greater than 0.5mm or with high air permeability and roughness) and other thin material.

Automatic Smoothness Tester Features

●  One-key test, easy and convenient.

●  Remove weights and use stepping motor with force sensor to complete the automatic pressurization step.

●  ARM processor improves the response speed of the instrument, and calculates data more accurately and quickly

●  Standard RS232 interface, with computer software for communication (Purchased separately)

Automatic Smoothness Tester Standards

GB/T 456，JJG62，ISO 5627

Automatic Smoothness Tester Technical Data
