ISO Flow Cups

Product Item : ZHIYI 25-120
Category： Viscosity
Product description：Ford Cups,ISO Flow Cups,Zahn Cups
INQUIRY

ISO Flow Cups are designed in accordance with International Standard ISO 2431, DIN 53224, EN 535 ASTM D5125 Paints and varnishes-Determination of flow time by Use of Flow Cups Fourth edition . They are made of
high quality aluminum and feature stainless steel nozzle inserts specification dependent . They are mirror polished smooth finished Ra 0.5 m ffor high efflux accuracy and easy maintenance. ISO Flow Cups are
applicable to Determine the flow time of Newtonian and near Newtonian fluids.

Technical Parameters :

*Material : Anodized Aluminum

*Weight :0.38kg

*Come with calibration certificate

ISO Flow Cups Detail Description :

Details/ISO Cups	ISO No.3	ISO No.4	ISO No.5	ISO No.6	ISO No.8
Orifice φ（mm）	3.0	4.0	5.0	6.0	8.0
Suitable Flow Time ( Sec)	30-100	30-100	30-100	30-100	30-100
Measurement Range (cSt)	7-42	34-135	91-326	188-684	600-2000
Model information	ZHIYI 7-42	ZHIYI 34-135	ZHIYI 91-326	ZHIYI 188-684	ZHIYI 600-2000
